Dental chair product details

Dental chair highlights

Key technical details are presented here so clinics and distributors can quickly compare the chair functions.

LED dental lamp

Tooth Smile LED dental lamp

Six-bulb LED dental light, 8,000 to 30,000 lux, with cold and warm light modes.

  • Philips LED bulbs for natural illumination
  • Adjustable brightness and color temperature
  • Digital control display for precise settings
  • Comfortable light spot designed to protect the eyes
Dental chair control panel

02 Adopted slope design

  • Intuitive human-machine interface
  • 30° to 80° adjustment range
  • Ergonomic design for easy access
  • Error code display for quick troubleshooting
Ultra-low dental chair position

03 Ultra-low chair position

  • Convenient for elderly patients and children
  • Ergonomic design for easy access
  • Customizable positioning for individual comfort
  • Enhances operational efficiency
Assistant arm anti-collision function

05 Assistant arm anti-collision

  • Auto-pause and reverse when an obstacle is detected
  • Reduces equipment damage and injury risk
  • Easy obstacle removal without complex intervention
  • Improves dental operatory safety
Doctor stool

06 Doctor stool

  • Seat height adjustable
  • Pneumatic lifting
  • Wide base for better stability
  • Innovative sliding design for easy installation
One-key smart drainage position

07 One-key smart drainage position

  • Single-button activation for end-of-day cleaning
  • Automatically raises the chair to the highest position
  • Triggers a 5-minute spittoon flushing cycle
  • Streamlines daily cleaning procedures

Injection molding process with a smooth, burr-free surface.

90° rotating side module gives dentists more working space.

Removable stainless steel instrument tray, easy to disinfect and clean.

Clear control panel, mobile operating table and quiet multidirectional casters.

Shadowless LED surgical light and pipe system with disinfection function.

R1 technical parameters

Power voltage
AC110V/220V +/-10V, 50Hz/60Hz
Motor
24V DC motor
Air pressure
> 0.55 MPa
Water pressure
0.2 MPa - 0.4 MPa
Illumination
> 5000 lx
Environment
5 degrees C - 40 degrees C, humidity <= 80% RH

Factory configuration

  • 2 high-speed handpiece tubes and 1 low-speed handpiece tube
  • 2 hot/cold 3-way syringes
  • Rotatable side box and rotatable/detachable ceramic spittoon
  • Strong/weak suction, water heater, main and assistant control systems
  • Luxury multifunction foot pedal, air brake instrument tray, imported air/water pipes
  • Synthetic leather cushion, double armrests and dentist stool

Comfort and accessories

  • Wide soft cushion, thinner backrest with ergonomic waist support
  • Seat height about 380 mm to 780 mm and -5 degree lying-flat position
  • 90 degree movable side box to free assistant working space
  • Brochure options: dental endoscope, disinfection system, suction, air compressor
  • Accessories: scaler, whitening instrument, light cure, electric motor and RX LED lamps
